Hydraulic High & Low Pressure Hoses

SAE 100 R1

Construction

Core

Black Color, Synthetic rubber resistant to oil and water

Reinforcement

Single steel wire braided

Cover

Black colour, Synthetic rubber resistant to abrasion and weather, oil & ozone

Application

Medium Pressure Hydraulic Hose for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Heavy machineries, Agriculture, Earthmoving & Material handling equipment.

Technical Specifications

Comprehensive Performance Data & Measurements

ID		OD		WP		BP
inch	mm	inch	mm	psi	bar	psi	bar
3/16	5.1	0.45	11.5	3625	250	14500	1000
1/4	6.7	0.52	13.1	3265	225	13050	900
5/16	8.2	0.58	14.7	3120	215	12470	860
3/8	9.8	0.67	17.1	2610	180	10440	720
1/2	13.1	0.80	20.2	2320	160	9280	640
5/8	16.2	0.92	23.3	1885	130	7540	520
3/4	19.3	1.07	27.3	1525	105	6090	420
1	25.9	1.39	35.3	1305	90	5150	355
1 1/4	32.4	1.69	43.0	945	65	3700	255
1 1/2	38.7	1.97	50.1	725	50	2900	200
2	51.3	2.50	63.4	580	40	2320	160
2 1/2	63.5	2.99	76.0	580	40	2105	145
3	76.2	3.56	90.5	510	35	2030	140
4	101.6	4.61	117.0	145	10	580	40

SAE 100 R2

Construction

Core

Black Color, Synthetic rubber resistant to oil and waterBlack colour, Synthetic rubber resistant to oil and water

Reinforcement

Double steel wire braided

Cover

Black colour, Synthetic rubber resistant to abrasion and weather, oil & ozoneBlack colour, Synthetic rubber resistant to abrasion and weather, oil & ozone

Application

High Pressure Hydraulic Hose for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Heavy machineries, Agriculture, Earthmoving & Material handling equipment.

Technical Specifications

Comprehensive Performance Data & Measurements

ID		OD		WP		BP
inch	mm	inch	mm	psi	bar	psi	bar
3/16	4.9	0.50	12.7	1525	105	6090	420
1/4	6.5	0.56	14.3	1305	90	5075	350
5/16	8.0	0.69	17.5	1235	85	4930	340
3/8	9.6	0.75	19.0	1160	80	4570	315
1/2	12.9	0.94	23.8	1015	70	4060	280
5/8	16.1	1.06	27.0	945	65	3560	245
3/4	19.2	1.25	31.8	800	55	3045	210
1	25.6	1.50	38.1	580	40	2320	160
1.1/4	32.1	1.75	44.5	435	30	1525	105
1.1/2	38.5	2.00	50.8	290	20	1015	70

SAE 100 R6

Construction

Core

Black colour, Synthetic rubber resistant to oil and weather

Reinforcement

Double fiber braided

Cover

Black colour, Synthetic rubber resistant to abrasion and weather, oil & ozone

Application

Low Pressure Hose for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Agriculture, & Material handling equipment

Technical Specifications

Comprehensive Performance Data & Measurements

ID		OD		WP		BP
inch	mm	inch	mm	psi	bar	psi	bar
3/16	4.8	0.44	11.1	510	35	2030	140
1/4	6.4	0.50	12.7	435	30	1670	115
5/16	8.0	0.56	14.3	435	30	1670	115
3/8	9.5	0.63	15.9	435	30	1670	115
1/2	12.7	0.78	19.8	435	30	1670	115
5/8	15.9	0.91	23.0	365	25	1450	100
3/4	19.1	1.05	26.6	365	25	1235	85
7/8	22	1.22	31.0	290	20	1160	80
1	25.6	1.33	33.8	220	15	870	60

4 SPIRAL HOSE (4SH)

Construction

Core

Black colour, Synthetic rubber resistant to oil and water

Reinforcement

Four high tensile steel wire spirals

Cover

Black colour, Synthetic rubber resistant to abrasion and weather, oil & ozone

Application

Extra High Pressure Hydraulic Hose for use with petroleum, synthetic or water based fluids in Hydraulic systems. Suitable for Heavy machineries, Agriculture, Earthmoving & Material handling equipment

Technical Specifications

Comprehensive Performance Data & Measurements

ID		RI OD		OD		WP		BP
inch	mm	inch	mm	inch	mm	psi	bar	psi	bar
3/4	19.4	1.12	28.4	1.27	32.2	6090	420	24360	1680
1	25.9	1.40	35.5	1.52	38.7	5510	380	22040	1520
1.1/4	32.5	1.65	41.9	1.79	45.5	4715	325	18850	1300
1.1/2	38.7	1.92	48.8	2.11	53.5	4205	290	16820	1160
2	51.3	2.49	63.2	2.68	68.1	3625	250	14500	1000
